What is the manned camera crane? Detailed interpretation of the manned camera crane

Parameter:

1. Arm length: 1.5 meters/pc
2.Tripod: total height 1.93 meters ; plus height 0.275 meters.

3. Manned seat (with 150 bowls)
4. Universial Dutch head holder: applicable for all type of dutch heads in the market.

    Two-way camera setting positon: The camera can go on top of the head holder or under
5. Heavy rail wheel:made of ABS plastic. Payload goes up to 600kgs.
6.Base weight: 12 meters --400 kilograms
7. Counterweight boxes: a big one and two small ones
8. Camera man can go on the crane for shooting when the crane is set at 6 or 8 meters.

The manned camera crane (also called a photographic elevator) is also a kind of rocker device, which is often used in film shooting and publicity. The effect of the camera crane is also used to manned shooting some big shot, the camera overhead, and the control arm is very similar, but there are a lot of difference.

Horse head (dutch head) holder                               Rail rollers: made from ABS material. Land/rail wheels

When the crane is set at length of 6 meters, people rides on the seat and shoot.

Safety belt is attached.

Arm payload: 200KGS

Counter weight.                                                        Counter weight box: 1 big and 1 small

Stent show: built with leveling poins which helps the eveness of the base and is used when the crane is used on the dolly rails. The man seat camera crane is rolled onto the rails.

Camera crane duth head connector            Camera crane seat with the camera bowl set aside.

Applicable for all the dutch heads such

as Ronin.

Introduction of EGF8 Manned camera crane

The biggest difference between a manned camera crane and an ordinary electric rocker is that the carrier arm of the manned camera crane is the cameraman, and the common camera crane is the camera equipment. The load-bearing capacity of the manned camera crane is very large, and the cameraman can manually control the camera on the front platform of the camera crane to complete the shooting of various lenses. The manned camera crane is used for precise control of the lens, such as the close range and the feature of the characters. Especially in the scene of film and TV scene, it can make the camera lens follow the photographer's thinking to capture the smooth and dynamic picture.

The load-bearing arm of the manned camera crane is large in size and weight in structural design. The ordinary rocker bearing is in the range of 30 kilograms, suitable for the use of different types of cameras. The load-bearing capacity of the manned camera crane is generally as high as hundreds of kilograms. Therefore, the structure and volume are more different than the ordinary rocker equipment, and more attention is paid to the stability and safety.

The manned camera crane has no electronic control system, and the cameraman manually controls the camera. But it can also achieve the "rise", "drop" "shake" "shift" shooting, in some shots than the electronic control rocker advantage more obvious. But because of the large volume and weight, they are relatively more manpower and material resources in installation and transportation. They have different advantages compared with the electric control rocker.

From the quality of the product itself to the installation, operation, and use of many other links can not be ignored. Proper installation, use and maintenance can not only provide efficiency, but also increase safety, stability and service life. Relevant staff must understand and familiarity with related knowledge.
